Metric Female Light (L) 24 Degree Seat

	Thread	Hose size (1/16")	Tube OD mm	Order Code	Available	1+	10+	50+
Metric Female Swivel Straight Light
	M14 x 1.5	-04	8L	132036	65	£15.42	£12.00	£9.81
	M16 x 1.5	-04	10L	132037	2	£17.16	£13.35	£10.92
	M16 x 1.5	-05	10L	132038	0	£16.88	£13.13	£10.74
	M18 x 1.5	-05	12L	132039	0	£17.05	£13.26	£10.85
	M16 x 1.5	-06	10L	132040	0	£20.72	£16.12	£13.19
	M18 x 1.5	-06	12L	132041	4	£16.33	£12.70	£10.39
	M22 x 1.5	-06	15L	132042	4	£21.48	£16.71	£13.67
	M22 x 1.5	-08	15L	132043	0	£19.66	£15.29	£12.51
	M30 x 2.0	-12	22L	132044	0	£35.13	£27.32	£22.35
	M45 x 2.0	-20	35L	132045	0	£75.11	£58.42	£47.80
Metric Female Swivel 45 Degree Light
	M12 x 1.5	-04	6L	132082	0	£31.97	£24.87	£20.34
	M14 x 1.5	-04	8L	132083	0	£30.70	£23.88	£19.54
	M16 x 1.5	-04	10L	132084	0	£30.55	£23.76	£19.44
	M16 x 1.5	-05	10L	132085	0	£33.86	£26.34	£21.55
	M16 x 1.5	-06	10L	132086	0	£31.97	£24.87	£20.34
	M18 x 1.5	-06	12L	132087	1	£29.14	£22.66	£18.54
	M22 x 1.5	-08	15L	132088	0	£35.52	£27.63	£22.61
	M26 x 1.5	-10	18L	132089	0	£44.78	£34.83	£28.50
	M30 x 2.0	-12	22L	132090	0	£59.15	£46.01	£37.64
	M36 x 2.0	-16	28L	132091	0	£79.80	£62.07	£50.78
	M36 x 2.0	-16	28L	132091	0	£79.80	£62.07	£50.78
	M45 x 2.0	-20	35L	132092	0	£174.54	£135.76	£111.07
	M52 x 2.0	-24	42L	132093	0	£213.85	£166.32	£136.08
Metric Female Swivel 90 Degree Light
	M12 x 1.5	-04	6L	132057	0	£31.97	£24.87	£20.34
	M14 x 1.5	-04	8L	132058	30	£30.45	£23.68	£19.38
	M16 x 1.5	-04	10L	132059	0	£30.55	£23.76	£19.44
	M16 x 1.5	-05	10L	132060	0	£33.86	£26.34	£21.55
	M18 x 1.5	-05	12L	132061	0	£61.47	£47.81	£39.12
	M16 x 1.5	-06	10L	132062	0	£31.97	£24.87	£20.34
	M18 x 1.5	-06	12L	132063	2	£29.14	£22.66	£18.54
	M22 x 1.5	-08	15L	132064	2	£35.52	£27.63	£22.61
	M26 x 1.5	-10	18L	132065	0	£49.97	£38.87	£31.80
	M30 x 2.0	-12	22L	132066	0	£69.31	£53.91	£44.10
	M36 x 2.0	-16	28L	132067	0	£86.87	£67.57	£55.28
	M45 x 2.0	-20	35L	132068	0	£174.54	£135.76	£111.07
	M52 x 2.0	-24	42L	132069	0	£213.85	£166.32	£136.08
